IP55 Motor Replenish Hydrogen Gas Reciprocating Compressor 200 bar compressor About
Product Parameter
|
Product Name
|
IP55 Motor Replenish Hydrogen Gas Reciprocating Compressor
|
|
Compress Medium
|
Regenerated gas Reciprocating Compressor
|
|
Model No.
|
2D3.5W-25/949
|
|
Type
|
L type diaphragm compressor
|
|
Rated flow rate (F.A.D)
|
25Nm3/min
|
|
Power
|
132KW
|
|
Suction pressure(G)
|
0.9Mpa
|
|
Rated outlet pressure
|
4.9Mpa
|
|
Transmission mode
|
Direct Driven
|
|
Cooling method
|
Industrial circulating water cooling tower
|
|
Dimension
|
5400*3500*2200mm
|
|
Weight
|
8t
|
|
Motor Speed
|
485 r/min
|
|
Voltage
|
380V, other voltage for special customize for each order
|
|
After-sales Service
|
Engineers available to service overseas
|
|
OEM
|
Welcomed (we have 5professional R&D engineers to do design & customizing service according to client's different requirement)
|
Specification
|
Motor type:
|
Y Series, Three Phases, Asynchronism
|
Compressor
|
1pc
|
|
Explosion proof grade
|
dIICT4
|
Primary intake and exhaust buffer tank
|
2set
|
|
Motor power:
|
132kW
|
Second level intake and exhaust buffer tank
|
1 set
|
|
Motor speed
|
485rpm
|
interstage cooler
|
1 set
|
|
Motor voltage
|
380V
|
Local PLC& Control instrument
|
1 set
|
|
Motor frequency
|
50 Hz
|
Inlet,outlet double flange & connect bolt
|
1 set
|
|
Protection level
|
IP 54
|
foundation bolt;
|
1 set
|
|
Insulation grade
|
Class F
|
Random spare parts
|
1 set
|
|
Anticorrosion grade
|
|
Random special tools
|
1 set
|
Silent and Efficient Hydrogen CompressionBenefit from near-silent operation and advanced diaphragm technology with the IP55 Motor Replenish Hydrogen Gas Compressor. Its oil-free mechanism preserves gas purity, while its stationary installation and robust build ensure consistent, uninterrupted industrial performance every day.
Versatile Power CompatibilityCompatible with multiple voltage settings-including 380V, 415V, 440V, 600V, and 660V-this compressor fits into various global industrial power infrastructures. The AC-powered design allows smooth operation across facilities without significant modifications.
Industrial Durability and Warranty SupportManufactured with high-grade materials in China, this compressor is built to withstand demanding operational environments. Supplied by reputable distributors and backed by a one-year warranty, users can rely on both the machine's performance and after-sales assistance.
FAQ's of IP55 Motor Replenish Hydrogen Gas Reciprocating Compressor 200 bar compressor:
Q: How does the oil-free diaphragm design benefit industrial hydrogen compression?
A: The oil-free diaphragm system maintains hydrogen gas purity during compression, preventing oil contamination and ensuring safe, clean gas delivery suitable for sensitive industrial applications.
Q: What are the primary uses of the IP55 Motor Hydrogen Gas Compressor?
A: This compressor is primarily used in industrial sectors requiring high-pressure hydrogen gas replenishment, such as chemical manufacturing, energy storage, and hydrogen fueling infrastructure.
Q: When should this compressor be serviced for optimal performance?
A: Regular maintenance is recommended according to the manufacturer's guidelines, typically after a set number of operating hours or at least annually, ensuring longevity and reliable output.
Q: Where can the compressor be installed?
A: Designed as a stationary unit, the compressor is ideal for indoor industrial locations with appropriate space and ventilation, meeting the specified size and safety requirements.
Q: What is the process for hydrogen gas compression in this unit?
A: Hydrogen gas enters the compressor and is pressurized through a reciprocating diaphragm mechanism. The oil-free design ensures no oil comes in contact with the gas throughout the compression process.
Q: What is included in the warranty provided for this product?
A: The compressor comes with a one-year warranty covering manufacturing defects and performance issues, ensuring support from suppliers, exporters, or manufacturers in China.
Q: How does the silent feature enhance its operation in industrial environments?
A: The silent operation reduces noise pollution within the facility, creating a safer and more comfortable work environment for employees while maintaining high-capacity hydrogen compression.
